Outer Diameter

107 mm (4.21 inch)

Thread Size

M26 x 1.5

Length

153 mm (6.02 inch)

Gasket OD

73 mm (2.87 inch)

Gasket ID

56 mm (2.20 inch)

Efficiency

50% 16 micron

Efficiency Test Std

SAE J806

Anti-Drainback Valve

Yes

Bypass Valve

Yes

Bypass Valve Setting LR

1.7 bar (25 psi)

Bypass Valve Setting HR

2.1 bar (30 psi)

Media Type

Cellulose

Collapse Burst

6.9 bar (100 psi)

Type

Full-Flow

Style

Spin-On

Primary Application

HINO 156071480

UPC Code

742330106594
