Type

Lube Filter

Style

Spin-On

Flow

Full Flow

Outer Diameter

93 mm (3.66 inch)

Thread Size

M24 x 1.5

Length

200 mm (7.87 inch)

Gasket OD

72 mm (2.83 inch)

Gasket ID

62 mm (2.44 inch)

Efficiency 99%

26 micron

Efficiency Test Std

ISO 16889

Anti-Drainback Valve

Yes

Bypass Valve

Yes

Bypass Valve Setting LR

2.1 bar (30 psi)

Bypass Valve Setting HR

2.55 bar (37 psi)

Media Type

Cellulose

Primary Application

CATERPILLAR 2698325

UPC Code

742330200414
